TEMPERATURE & HUMIDITY TRANSMITTER 4-20mA WITH DISPLAY

Overview:

The temperature & Humidity Transmitter with Display precisely measures environmental temperature and relative humidity, converting readings into reliable 4-20mA output signals. Ideal for industrial and commercial applications, this device combines accuracy, durability, and ease of installation.

Key Features:

• Accurate & Precise Measurement: Temperature accuracy ±0.3°C, humidity accuracy ±3% RH

• 4-20mA Analogue Output: Reliable standard signal for industrial monitoring and control systems

• Durable Design: IP67 plastic casing (sensor not included) protects the device in harsh environments

• Long Operating Life: Engineered for reliability and extended use

• Cleanable Filter: Ensures stable performance and longevity

• Easy Assembly: User-friendly installation with compact dimensions

Technical Specifications:

Parameter	Measuring Range	Sensitivity	Accuracy
Temperature	0–50°C (−20 to +80°C)	±0.1°C	±0.3°C
Humidity	0–100% RH	±1%	±3%



Dimensions:

• Overall: 172 mm (A) × 65 mm (B) × 40 mm (C)

• Sensor Mounting: 115 mm (a) × 36 mm (b) × 20 mm (c)

Applications:

Perfect for industrial monitoring, HVAC systems, environmental control, and any application requiring precise temperature and humidity readings with a 4-20mA output for control systems.
